ADNM – VW (Dynamic White)

Low voltage, DMX control, electronic transformer for indoor applications. ADNM-VW is designed for Tunable White products.

ADNM – VW (Dynamic White)

FEATURES

Switching electronic power supply
Constant Voltage
Universal input voltage: 100-277V AC
Single and multiple 12V or 24V DC outputs
NEMA 3R Rain-tight enclosure for wet locations
5 year warranty

ENVIRONMENTAL

MTBF: 100,000 hrs. at full load and 25°C
Operating temperature: -40°C – +80°C (Full load)
Storage temperature: -65°C – +90°C
Heat dissipation: Convection

ELECTRICAL DATA

Secondary circuit maximum protection for Class 2 circuits: 5A for 12V DC 4A for 24V DC
Voltage regulated
Auto overload / short circuit / over voltage protection
50/60 Hz

MOUNTING

Steel Enclosure
Bracket mount and ½” knockouts for conduit and fittings

Specs

Dimming = DMX
Environment = Dry, Damp, Wet Location
Class Rating = Class 2
Circuit Breakers = 1, 2, 3
Max Load = 90W, 96W, 192W, 288W
Circuit Capacity = 3.75A, 4A
Primary Voltage = 100-277V AC
Secondary Voltage = 24V DC
Warranty = 5

Downloads

Specification
ADNM VW Specification
Installation
ADNM VW Installation
