ELITE High Output

ELITE High Output TivoTape offers high CRI up to 95, and with an R9 value of 83, making color look natural and standout. At 103- 124 Lm/W efficacy and backed with a 4oz. copper trace ELITE delivers consistent quality throughout the entire run with virtually no lumen drop.

ELITE High Output

Features

Low bin tolerance with a 1.5 Step McAdam Elipse standard
Factory produced with Tivoli’s eXo Shield coating
High CRI value
Factory soldered leadwire requireds
IP67 Wet location available
Multiple mounting channel options
Large range of available Kelvin temperatures
Low lead times
4oz. Copper Trace

Mounting

3M VHB Tape (factory installed)

Specs

Voltage = 24V DC
Power Consumption (W/ft) = 4.5W
Max Run (ft) = 20'
Dimming = MLV, ELV, 0-10V, DMX
Environment = Dry Location
IP Rating = IP54
LED Color ( Kelvin Temp ) = 2200K, 2400K, 2700K, 3000K, 3500K, 4000K, 5000K
CRI = 90+
Lumen Output (lm/ft) = 400-500, 500+
Efficacy (lm/W) = Up To 117
Lumen Maintenance (L70) Hours = 60,000
Certifications = cULus
Warranty = 5 Years

Similar Products

High CRI - Vision Series

ELITE+ Vision Series

High Efficacy - Pro Series

ELITE+ Pro Series

Over All Performance - ELITE+ Series

ELITE Standard Brightness

ELITE Very High Output

Downloads

Specification
ELITE HO Factory Prep Specification
Installation
ELITE HO Factory Prep Indoor Installation
IES File
TPLE-HO-I-30-24
TM-30 Report
ELITE HO TM-30

COMPATIBLE EXTRUSION

DYER

Infinity

ASTORIA

MOFETT

VALENCIA

MINI

DOME

HORIZON

NOYES

WARNER

DEWAR

EDGE

Case Studies

No images found in the case studies gallery.

Gallery
